LS-45V24-DALI2 (24V 45W)

Description

LS-45V24-DALI2

LED power supply for 24 Vdc constant voltage
1.88 A (45W) max., IP20, independent installation
Dimmable with DALI, PUSH (pri.)
Flickerfree according to IEEE 1789

Electrical Data

Input Voltage (nominal)	220…240 Vac
Input Voltage (range)	176…264 Vac
Mains Frequency	50/60 Hz
Power Factor (λ)	≥0.9 Full Load, 230 Vac
Input Current	0.35 A max. Full Load, 176 Vac
Inrush Current	40 A max.
Leakage Current	< 0,5 mA 240 Vac
Output Voltage	24 Vdc
Output Current	1.88 A max.
Output Power (nominal)	45 W max.
Efficiency	≥ 86 %
Life Time	> 44,000 h
Dimming mode	DALI, PUSH (pri.)

Operating Condition

Operating temperature range (ta)	-25…+50 °C
Max. Surface Temperature (tc)	85 °C
Permitted rel. Humidity	20…95 %
Protection Class	II
Type of Protection	IP20

Protection

Short Circuit Protection	Yes *
Overload Protection	Yes *
Overvoltage Protection	Yes *
Overheating Protection	Yes *

(*) The output shuts off and will be resumed, after problem is removed and led driver is restarted.

Standards & Certificates

Standards (LVD)	EN 61347-1, EN 61347-2-13 EN 62384
Standards (EMC)	EN 61000-3-2, EN 61000-3-3 EN 61000-4-2, EN 61000-4-5 EN 55015, EN 61547
Approval Marks	CE
RoHS Compliant	Yes

Installation

Type of Installation	Independent installation
Type of Connection	Screw terminal
Cable Cross-Section, input side	0.5…1.5 mm²
Cable Cross-Section, output side	0.5…1.5 mm²
Cable Preparation Length, input side	7…9 mm
Cable Preparation Length, output side	7…9 mm
